| 分项Item | 技术参数 Technical parameter | ||
|
型号
Type
|
PH2.0 | PH2.5 | |
|
单元板尺寸
Dimension
|
160mm*80mm | 160mm*80mm | |
|
点间距离
Pixel pitch
|
2.0mm | 2.5mm | |
| 单 |
物理密度
Pixel Density
|
250000 / M2 | 160000/ M2 |
| 元 |
发光点颜色
Pixel configuration
|
1R1G1B | 1R1G1B |
| 板 |
灯体
LED specification
|
SMD1515（HG） | SMD2020（HG） |
| Panel |
单元板分辨率
Pixel resolution
|
（W）80*40（H） | （W）64*32（H） |
|
单元板平均功率
Average power
|
7W | 7W | |
|
单元板电流
Panel current
|
1.4A 5V | 1.4A 5V | |
|
单元板重量
Panel weight
|
155g | 155g | |
|
箱体 Cabinet&
Bracket
|
湿度
Humidity
|
10%-95%RH | 10%-95%RH |
|
单元板数量
Quantity of panel
|
78 | 78 | |
|
单元板接口
Hub connecting
|
HUB75 16pin | HUB75 16pin | |
|
最佳视角
Best viewing angle
|
Horizontal >140 Vertical>120 | Horizontal >140 Vertical>120 | |
|
最佳视距
Best viewing distance
|
2-10M | 3-20M | |
|
工作温度
Working temperature
|
-20-~60 degree | -20-~60 degree | |
|
单元板供电
Panel power supply
|
5V40A | 5V40A | |
|
屏体供电
Screen power supply
|
220VAC/50HZ+_10% | 220VAC/50HZ+_10% | |
|
最大功率
Max power
|
<650W/M² | <650W/M² | |
|
平均功率
Average power
|
200W | 200W | |
|
电源使用数量
Power quantity
|
200W/24PCS | 200W/24PCS | |
|
驱动器件
Driving device
|
FM6363
Constant current drive
|
ICN2037
Constant current drive
|
|
| 技 |
扫描方式
Drive type
|
1/32 Scanning | 1/32 Scanning |
| 术 |
刷新频率
Refresh frequency
|
≥3840HZ/S | ≥1920HZ/S |
| 参 |
显示颜色
Display color
|
4096*4096*4096 | 4096*4096*4096 |
| 数 |
亮度
Brightness
|
650 cd/M2 | 650cd/M2 |
|
使用寿命
Life span
|
100000Hours | 100000Hours | |
|
防水等级
Waterproof Grade
|
IP33 | IP33 | |
| 分项Item | 技术参数 Technical parameter | ||||||||
|
型号 Type |
PH1.25 | PH1.53 | PH1.86 | PH2.0 | PH2.5 | PH3.076 | PH4 | PH5 | |
| 单元板尺寸 Dimension | 320mm*160mm | 320mm*160mm | 320mm*160mm | 320mm*160mm | 320mm*160mm | 320mm*160mm | 320mm*160mm | 320mm*160mm | |
|
点间距离 Pixel pitch |
1.25mm | 1.53mm | 1.86mm | 2.0 mm | 2.5 mm | 3.076mm | 4mm | 5mm | |
| 单 |
物理密度 Pixel Density |
640000/ M2 | 422500/ M2 | 288906/ M2 | 250000/ M2 | 160000/ M2 | 105625/ M2 | 62500/ M2 | 40000/ M2 |
| 元 |
发光点颜色 Pixel configuration |
1R1G1B | 1R1G1B | 1R1G1B | 1R1G1B | 1R1G1B | 1R1G1B | 1R1G1B | 1R1G1B |
| 板 |
灯体 LED specification |
SMD1010（HG） | SMD1212（HG） | SMD1515（HG） | SMD1515（HG） | SMD2020（HG） | SMD2020（HS） | SMD2020（HS） | SMD2020（HS） |
| Panel | 单元板分辨率 Pixel resolution | （W）256*128（H） | （W）208*104（H） | （W）172*86（H） | （W）160*80（H） | （W）128*64（H） | （W）104*52（H） | （W）80*40（H） | （W）64*32（H） |
| 单元板平均功率 Average power | 35W | 26W | 26W | 26W | 26W | 26W | 25W | 18W | |
| 单元板电流 Panel current | 7A 5V | 5.2A 5V | 5.2A 5V | 5.2A 5V | 5.2A 5V | 5.2A 5V | 5A 5V | 3.6A 5V | |
| 单元板重量 Panel weight | 0.4 KG | 0.4 KG | 0.4 KG | 0.4 KG | 0.4 KG | 0.4 KG | 0.4KG | 0.4 KG | |
|
箱体 Cabinet& Bracket |
湿度 Humidity |
10%-95%RH | 10%-95%RH | 10%-95%RH | 10%-95%RH | 10%-95%RH | 10%-95%RH | 10%-95%RH | 10%-95%RH |
| 单元板数量 Quantity of panel | 19.5 | 19.5 | 19.5 | 19.5 | 19.5 | 19.5 | 19.5 | 19.5 | |
|
单元板接口 Hub connecting |
HUB320 26pin | HUB75 16pin | HUB75 16pin | HUB75 16pin | HUB75 16pin | HUB75 16pin | HUB75 16pin | HUB75 16pin | |
|
最佳视角 Best viewing angle |
Horizontal >140 Vertical>120 | Horizontal >140 Vertical>120 | Horizontal >140 Vertical>120 | Horizontal >140 Vertical>120 | Horizontal >140 Vertical>120 | Horizontal >140 Vertical>120 | Horizontal >140 Vertical>120 | Horizontal >140 Vertical>120 | |
| 最佳视距 Best viewing distance | 2-10M | 3-30M | 2-10M | 2-10M | 2-10M | 2-10M | 4-30M | 2-10M | |
| 工作温度 Working temperature | -20-~60 degree | -20-~60 degree | -20-~60 degree | -20-~60 degree | -20-~60 degree | -20-~60 degree | -20-~60 degree | -20-~60 degree | |
| 单元板供电 Panel power supply | 5V60A | 5V40A | 5V40A | 5V40A | 5V40A | 5V40A | 5V40A | 5V40A | |
| 屏体供电 Screen power supply | 220VAC/50HZ+_10% | 220VAC/50HZ+_10% | 220VAC/50HZ+_10% | 220VAC/50HZ+_10% | 220VAC/50HZ+_10% | 220VAC/50HZ+_10% | 220VAC/50HZ+_10% | 220VAC/50HZ+_10% | |
|
最大功率 Max power |
<650W/M² | <700W/M² | <650W/M² | <650W/M² | <650W/M² | <650W/M² | <800W/M² | <650W/M² | |
|
平均功率 Average power |
200W | 210W | 200W | 200W | 200W | 200W | 60W | 200W | |
| 电源使用数量 power quantity | 300W/6PCS | 200W/6PCS | 200W/6PCS | 200W/6PCS | 200W/6PCS | 200W/6PCS | 200W/6PCS | 200W/8PCS | |
|
驱动器件 Driving device |
FM6363 Constant current drive |
FM6363 Constant current drive |
FM6363 Constant current drive |
FM6363 Constant current drive |
FM6363 Constant current drive |
ICN2037 Constant current drive |
ICN2037 Constant current drive |
ICN2037 Constant current drive |
|
| 技 |
扫描方式 Drive type |
1/64 Scanning | 1/52 Scanning | 1/52 Scanning | 1/40 Scanning | 1/32 Scanning | 1/26 Scanning | 1/20 Scanning | 1/16 Scanning |
| 术 | 刷新频率 Refresh frequency | ≥3840HZ/S | ≥3840HZ/S | ≥3840HZ/S | ≥3840HZ/S | ≥3840HZ/S | ≥1920HZ/S | ≥1920HZ/S | ≥3840HZ/S |
| 参 |
显示颜色 Display color |
4096*4096*4096 | 4096*4096*4096 | 4096*4096*4096 | 4096*4096*4096 | 4096*4096*4096 | 4096*4096*4096 | 4096*4096*4096 | 4096*4096*4096 |
| 数 |
亮度 Brightness |
650 cd/M2 | 650cd/M2 | 650cd/M2 | 650 cd/M2 | 650 cd/M2 | 700cd/M2 | 700cd/M2 | 700cd/M2 |
|
使用寿命 Life span |
100000Hours | 100000Hours | 100000Hours | 100000Hours | 100000Hours | 100000Hours | 100000Hours | 100000Hours | |
|
防水等级 Waterproof Grade |
IP33 | IP33 | IP33 | IP33 | IP33 | IP33 | IP33 | IP33 | |
| 分项Item | 技术参数 Technical parameter | ||
|
型号
Type
|
PH2.0 | PH4 | |
|
单元板尺寸
Dimension
|
256mm*128mm | 256mm*128mm | |
|
点间距离
Pixel pitch
|
2.0mm | 4mm | |
| 单 |
物理密度
Pixel Density
|
250000 / M2 | 62500/ M2 |
| 元 |
发光点颜色
Pixel configuration
|
1R1G1B | 1R1G1B |
| 板 |
灯体
LED specification
|
SMD1515（HG） | SMD2020（HG） |
| Panel |
单元板分辨率
Pixel resolution
|
（W）128*64（H） | （W）64*32（H） |
|
单元板平均功率
Average power
|
15W | 16W | |
|
单元板电流
Panel current
|
3A 5V | 3.2A 5V | |
|
单元板重量
Panel weight
|
185g | 200g | |
|
箱体 Cabinet&
Bracket
|
湿度
Humidity
|
10%-95%RH | 10%-95%RH |
|
单元板数量
Quantity of panel
|
30.5 | 30.5 | |
|
单元板接口
Hub connecting
|
HUB75 16pin | HUB75 16pin | |
|
最佳视角
Best viewing angle
|
Horizontal >140 Vertical>120 | Horizontal >140 Vertical>120 | |
|
最佳视距
Best viewing distance
|
2-10M | 4-30M | |
|
工作温度
Working temperature
|
-20-~60 degree | -20-~60 degree | |
|
单元板供电
Panel power supply
|
5V40A | 5V40A | |
|
屏体供电
Screen power supply
|
220VAC/50HZ+_10% | 220VAC/50HZ+_10% | |
|
最大功率
Max power
|
<650W/M² | <700W/M² | |
|
平均功率
Average power
|
200W | 210W | |
|
电源使用数量
Power quantity
|
200W/8PCS | 200W/8PCS | |
|
驱动器件
Driving device
|
FM6363
Constant current drive
|
ICN2037
Constant current drive
|
|
| 技 |
扫描方式
Drive type
|
1/32 Scanning | 1/16 Scanning |
| 术 |
刷新频率
Refresh frequency
|
≥3840HZ/S | ≥1920HZ/S |
| 参 |
显示颜色
Display color
|
4096*4096*4096 | 4096*4096*4096 |
| 数 |
亮度
Brightness
|
650 cd/M2 | 700cd/M2 |
|
使用寿命
Life span
|
100000Hours | 100000Hours | |
|
防水等级
Waterproof Grade
|
IP33 | IP33 | |
| 技术参数 Technical parameter | |||
| 单元板尺寸 Dimension | 192mm*192mm | 192mm*192mm | 192mm*192mm |
|
点间距离 Pixel pitch |
1.5mm | 3.0mm | 6.0mm |
|
物理密度 Pixel Density |
444444 / M2 | 111111 / M2 | 27777 / M2 |
|
发光点颜色 Pixel configuration |
1R1G1B | 1R1G1B | 1R1G1B |
|
灯体 LED specification |
SMD1212（HG） | SMD2020（HG） | SMD3528（HG） |
| 单元板分辨率 Pixel resolution | （W）128*128（H） | （W）64*64（H） | （W）32*32（H） |
| 单元板平均功率 Average power | 15W | 15W | 24W |
| 单元板电流 Panel current | 3A 5V | 3A 5V | 4.8A 5V |
| 单元板重量 Panel weight | 300g | 300g | 300g |
|
湿度 Humidity |
10%-95%RH | 10%-95%RH | 10%-95%RH |
| 单元板数量 Quantity of panel | 27.12 | 27.12 | 27.12 |
|
单元板接口 Hub connecting |
HUB75 16pin | HUB75 16pin | HUB75 16pin |
|
最佳视角 Best viewing angle |
Horizontal >140 Vertical>120 | Horizontal >140 Vertical>120 | Horizontal >140 Vertical>120 |
| 最佳视距 Best viewing distance | 2-10M | 3-10M | 3-30M |
| 工作温度 Working temperature | -20~60 degree | -20~60 degree | -20~60 degree |
| 单元板供电 Panel power supply | 5V60A | 5V40A | 5V40A |
| 屏体供电 Screen power supply | 220VAC/50HZ+_10% | 220VAC/50HZ+_10% | 220VAC/50HZ+_10% |
|
最大功率 Max power |
<650W/M² | <600W/M² | <600W/M² |
|
平均功率 Average power |
200W | 180W | 180W |
| 电源使用数量 power quantity | 200W/9PCS | 200W/9PCS | 200W/8PCS |
|
驱动器件 Driving device |
FM6363 Constant current drive |
ICN2037 Constant current drive |
ICN2037 Constant current drive |
|
扫描方式 Drive type |
1/64 Scanning | 1/32 Scanning | 1/16 Scanning |
| 刷新频率 Refresh frequency | ≥3840HZ/S | ≥3840HZ/S | ≥3840HZ/S |
|
显示颜色 Display color |
4096*4096*4096 | 4096*4096*4096 | 4096*4096*4096 |
|
亮度 Brightness |
650 cd/M2 | 800 cd/M2 | 1000 cd/M2 |
|
使用寿命 Life span |
100000Hours | 100000Hours | 100000Hours |
|
防水等级 Waterproof Grade |
IP33 | IP33 | IP33 |
| 分项Item | 技术参数 Technical parameter | |||
|
型号
Type
|
PH1.904 | PH2.5 | PH5 | |
| 单元板尺寸 Dimension | 160mm*160mm | 160mm*160mm | 160mm*160mm | |
|
点间距离
Pixel pitch
|
1.904mm | 2.5mm | 5mm | |
| 单 |
物理密度
Pixel Density
|
275625 / M2 | 160000 / M2 | 40000 / M2 |
| 元 |
发光点颜色
Pixel configuration
|
1R1G1B | 1R1G1B | 1R1G1B |
| 板 |
灯体
LED specification
|
SMD1515（HS） | SMD2020（HS） | SMD2020（HS） |
| Panel | 单元板分辨率 Pixel resolution | （W）84*84（H） | （W）64*64（H） | （W）32*32（H） |
| 单元板平均功率 Average power | 15W | 13W | 12W | |
| 单元板电流 Panel current | 3A 5V | 2.6A 5V | 2.4A 5V | |
| 单元板重量 Panel weight | 300g | 300g | 300g | |
|
箱体 Cabinet&
Bracket
|
湿度
Humidity
|
10%-95%RH | 10%-95%RH | 10%-95%RH |
| 单元板数量 Quantity of panel | 39.06 | 39.06 | 39.06 | |
|
单元板接口
Hub connecting
|
HUB75 16pin | HUB75 16pin | HUB75 16pin | |
|
最佳视角
Best viewing angle
|
Horizontal >140 Vertical>120 | Horizontal >140 Vertical>120 | Horizontal >140 Vertical>120 | |
| 最佳视距 Best viewing distance | 2-10M | 3-10M | 3-30M | |
| 工作温度 Working temperature | -20~60 degree | -20~60 degree | -20~60 degree | |
| 单元板供电 Panel power supply | 5V40A | 5V40A | 5V40A | |
| 屏体供电 Screen power supply | 220VAC/50HZ+_10% | 220VAC/50HZ+_10% | 220VAC/50HZ+_10% | |
|
最大功率
Max power
|
<650W/M² | <600W/M² | <600W/M² | |
|
平均功率
Average power
|
200W | 180W | 180W | |
| 电源使用数量 power quantity | 200W/12PCS | 200W/12PCS | 200W/12PCS | |
|
驱动器件
Driving device
|
FM6363
Constant current drive
|
ICN2037
Constant current drive
|
ICN2037
Constant current drive
|
|
| 技 |
扫描方式
Drive type
|
1/28 Scanning | 1/32 Scanning | 1/16 Scanning |
| 术 | 刷新频率 Refresh frequency | ≥3840HZ/S | ≥1920HZ/S | ≥1920HZ/S |
| 参 |
显示颜色
Display color
|
4096*4096*4096 | 4096*4096*4096 | 4096*4096*4096 |
| 数 |
亮度
Brightness
|
800 cd/M2 | 650 cd/M2 | 1000 cd/M2 |
|
使用寿命
Life span
|
100000Hours | 100000Hours | 100000Hours | |
|
防水等级
Waterproof Grade
|
IP33 | IP33 | IP33 | |
| 技术参数 Technical parameter | ||
| 单元板尺寸 Dimension | 128mm*128mm | 128mm*128mm |
|
点间距离 Pixel pitch |
2.0 mm | 4.0 mm |
|
物理密度 Pixel Density |
250000/ M2 | 62500/ M2 |
|
发光点颜色 Pixel configuration |
1R1G1B | 1R1G1B |
|
灯体 LED specification |
SMD1515（HG） | SMD2020（HG） |
|
单元板分辨率 Pixel resolution |
（W）64*64（H） | （W）32*32（H） |
|
单元板平均功率 Average power |
8W | 8W |
|
单元板电流 Panel current |
1.6A 5V | 1.6A 5V |
|
单元板重量 Panel weight |
100g | 100g |
|
湿度 Humidity |
10%-95%RH | 10%-95%RH |
|
单元板数量 Quantity of panel |
78 | 78 |
|
单元板接口 Hub connecting |
HUB75 16pin | HUB75 16pin |
|
最佳视角 Best viewing angle |
Horizontal >140 Vertical>120 | Horizontal >140 Vertical>120 |
|
最佳视距 Best viewing distance |
2-10M | 2-10M |
| 工作温度 Working temperature | -80 | -80 |
|
单元板供电 Panel power supply |
5V40A | 5V40A |
|
屏体供电 Screen power supply |
220VAC/50HZ+_10% | 220VAC/50HZ+_10% |
|
最大功率 Max power |
<650W/M² | <650W/M² |
|
平均功率 Average power |
200W | 200W |
|
电源使用数量 Power quantity |
200W/16PCS | 200W/16PCS |
|
驱动器件 Driving device |
ICN2153 Constant current drive |
ICN2037 Constant current drive |
|
扫描方式 Drive type |
1/40 Scanning | 1/32 Scanning |
|
刷新频率 Refresh frequency |
≥3840HZ/S | ≥1920HZ/S |
|
显示颜色 Display color |
4096*4096*4096 | 4096*4096*4096 |
|
亮度 Brightness |
650 cd/M2 | 650 cd/M2 |
|
使用寿命 Life span |
100000Hours | 100000Hours |
|
防水等级 Waterproof Grade |
IP33 | IP33 |
| 分项Item | 技术参数 Technical parameter | |||
|
型号 Type |
PH4.75 | PH4.75 | PH4.75 | |
| 单元板尺寸 Dimension | 304mm*152mm | 304mm*152mm | 304mm*152mm | |
|
点间距离 Pixel pitch |
4.75mm | 4.75mm | 4.75mm | |
| 单 |
物理密度 Pixel Density |
44321 / M2 | 44321 / M2 | 44321 / M2 |
| 元 |
发光点颜色 Pixel configuration |
1R | 1R1G | 1R1G |
| 板 |
灯体 LED specification |
SMD2020 | SMD2020 | SMD3528 |
| Panel | 单元板分辨率 Pixel resolution | （W）64*32（H） | （W）64*32（H） | （W）32*16（H） |
| 单元板平均功率 Average power | 18W | 18W | 18W | |
| 单元板电流 Panel current | 3.6A 5V | 3.6A 5V | 3.6A 5V | |
| 单元板重量 Panel weight | 280g | 280g | 280g | |
|
箱体 Cabinet& Bracket |
湿度 Humidity |
10%-95%RH | 10%-95%RH | 10%-95%RH |
| 单元板数量 Quantity of panel | 21.64 | 21.64 | 21.64 | |
|
单元板接口 Hub connecting |
HUB12 16pin | HUB08 16pin | HUB08 16pin | |
|
最佳视角 Best viewing angle |
Horizontal >140 Vertical>120 | Horizontal >140 Vertical>120 | Horizontal >140 Vertical>120 | |
| 最佳视距 Best viewing distance | 4-10M | 4-10M | 8-30M | |
| 工作温度 Working temperature | -20~60 degree | -20~60 degree | -20~60 degree | |
| 单元板供电 Panel power supply | 5V40A | 5V40A | 5V40A | |
| 屏体供电 Screen power supply | 220VAC/50HZ+_10% | 220VAC/50HZ+_10% | 220VAC/50HZ+_10% | |
|
最大功率 Max power |
<389W/M² | <389W/M² | <389W/M² | |
|
平均功率 Average power |
116W | 116W | 116W | |
| 电源使用数量 power quantity | 200W/8PCS | 200W/8PCS | 200W/8PCS | |
|
驱动器件 Driving device |
INC2037 Constant current drive |
INC2037 Constant current drive |
ICN2037 Constant current drive |
|
| 技 |
扫描方式 Drive type |
1/16 Scanning | 1/16 Scanning | 1/16 Scanning |
| 术 | 刷新频率 Refresh frequency | ≥1920HZ/S | ≥1920HZ/S | ≥1920HZ/S |
| 参 |
显示颜色 Display color |
4096*4096*4096 | 4096*4096*4096 | 4096*4096*4096 |
| 数 |
亮度 Brightness |
800 cd/M2 | 800 cd/M2 | 1500 cd/M2 |
|
使用寿命 Life span |
100000Hours | 100000Hours | 100000Hours | |
|
防水等级 Waterproof Grade |
Front side & Back side IP33 | Front side & Back side IP33 | Front side & Back side IP33 | |
| 分项Item | 技术参数 Technical parameter | |
|
型号
Type
|
PH4 | |
|
单元板尺寸
Dimension
|
256mm*256mm | |
|
点间距离
Pixel pitch
|
4mm | |
| 单 |
物理密度
Pixel Density
|
62500 / M2 |
| 元 |
发光点颜色
Pixel configuration
|
1R1G1B |
| 板 |
灯体
LED specification
|
SMD2020（HS） |
| Panel |
单元板分辨率
Pixel resolution
|
（W）64*64（H） |
|
单元板平均功率
Average power
|
16W | |
|
单元板电流
Panel current
|
3A 5V | |
|
单元板重量
Panel weight
|
380g | |
|
箱体 Cabinet&
Bracket
|
湿度
Humidity
|
10%-95%RH |
|
单元板数量
Quantity of panel
|
15.25 | |
|
单元板接口
Hub connecting
|
HUB75 16pin | |
|
最佳视角
Best viewing angle
|
Horizontal >140 Vertical>120 | |
|
最佳视距
Best viewing distance
|
4-20M | |
|
工作温度
Working temperature
|
-20~60 degree | |
|
单元板供电
Panel power supply
|
5V40A | |
|
屏体供电
Screen power supply
|
220VAC/50HZ+_10% | |
|
最大功率
Max power
|
<650W/M² | |
|
平均功率
Average power
|
200W | |
|
电源使用数量
Power quantity
|
200W/9PCS | |
|
驱动器件
Driving device
|
ICN2037
Constant current drive
|
|
| 技 |
扫描方式
Drive type
|
1/32 Scanning |
| 术 |
刷新频率
Refresh frequency
|
≥1920HZ/S |
| 参 |
显示颜色
Display color
|
4096*4096*4096 |
| 数 |
亮度
Brightness
|
650 cd/M2 |
|
使用寿命
Life span
|
100000Hours | |
|
防水等级
Waterproof Grade
|
IP33 | |
| 分项Item | 技术参数 Technical parameter | |||||
|
型号 Type |
PH1.953 | PH2.604 | PH2.976 | PH3.91 | PH4.81 | |
|
单元板尺寸 Dimension |
250mm*250mm | 250mm*250mm | 250mm*250mm | 250mm*250mm | 250mm*250mm | |
|
点间距离 Pixel pitch |
1.953mm | 2.604mm | 2.976mm | 3.91mm | 4.81mm | |
| 单 |
物理密度 Pixel Density |
262144 / M2 | 147456 / M2 | 112896 / M2 | 65536 / M2 | 43264 / M2 |
| 元 |
发光点颜色 Pixel configuration |
1R1G1B | 1R1G1B | 1R1G1B | 1R1G1B | 1R1G1B |
| 板 |
灯体 LED specification |
SMD1515（HS） | SMD2020（HS） | SMD2020（HS） | SMD2020（HS） | SMD2020（HS） |
| Panel |
单元板分辨率 Pixel resolution |
（W）128*128（H） | （W）96*96（H） | （W）84*84（H） | （W）64*64（H） | （W）52*52（H） |
|
单元板平均功率 Average power |
35W | 30W | 21W | 26W | 28W | |
|
单元板电流 Panel current |
7A 5V | 6A 5V | 4.2A 5V | 5.2A 5V | 5.6A 5V | |
|
单元板重量 Panel weight |
500g | 500g | 500g | 500g | 500g | |
|
箱体 Cabinet& Bracket |
湿度 Humidity |
10%-95%RH | 10%-95%RH | 10%-95%RH | 10%-95%RH | 10%-95%RH |
|
单元板数量 Quantity of panel |
16 | 16 | 16 | 16 | 16 | |
|
单元板接口 Hub connecting |
HUB75 16pin | HUB75 16pin | HUB75 16pin | HUB75 16pin | HUB75 16pin | |
|
最佳视角 Best viewing angle |
Horizontal >140 Vertical>120 | Horizontal >140 Vertical>120 | Horizontal >140 Vertical>120 | Horizontal >140 Vertical>120 | Horizontal >140 Vertical>120 | |
|
最佳视距 Best viewing distance |
2-10M | 3-10M | 3-10M | 4-20M | 5-30M | |
|
工作温度 Working temperature |
-20~60 degree | -20~60 degree | -20~60 degree | -20~60 degree | -20~60 degree | |
|
单元板供电 Panel power supply |
5V40A | 5V40A | 5V40A | 5V40A | 5V40A | |
|
屏体供电 Screen power supply |
220VAC/50HZ+_10% | 220VAC/50HZ+_10% | 220VAC/50HZ+_10% | 220VAC/50HZ+_10% | 220VAC/50HZ+_10% | |
|
最大功率 Max power |
<800W/M² | <800W/M² | <800W/M² | <800W/M² | <800W/M² | |
|
平均功率 Average power |
240W | 240W | 240W | 240W | 240W | |
|
电源使用数量 Power quantity |
200W/4PCS | 200W/4PCS | 200W/4PCS | 200W/4PCS | 200W/4PCS | |
|
驱动器件 Driving device |
ICN2037 Constant current drive |
ICN2037 Constant current drive |
ICN2037 Constant current drive |
ICN2037 Constant current drive |
ICN2037 Constant current drive |
|
| 技 |
扫描方式 Drive type |
1/32 Scanning | 1/32 Scanning | 1/26 Scanning | 1/16 Scanning | 1/13 Scanning |
| 术 |
刷新频率 Refresh frequency |
≥1920HZ/S | ≥1920HZ/S | ≥1920HZ/S | ≥1920HZ/S | ≥1920HZ/S |
| 参 |
显示颜色 Display color |
4096*4096*4096 | 4096*4096*4096 | 4096*4096*4096 | 4096*4096*4096 | 4096*4096*4096 |
| 数 |
亮度 Brightness |
800 cd/M2 | 800 cd/M2 | 800 cd/M2 | 800 cd/M2 | 800 cd/M2 |
|
使用寿命 Life span |
100000Hours | 100000Hours | 100000Hours | 100000Hours | 100000Hours | |
|
防水等级 Waterproof Grade |
IP33 | IP33 | IP33 | IP33 | IP33 | |
| 分项Item | 技术参数 Technical parameter | |||
|
型号 Type |
PH1.875 | PH2.5 | PH3.0 | |
|
单元板尺寸 Dimension |
240mm*240mm | 240mm*240mm | 240mm*240mm | |
|
点间距离 Pixel pitch |
1.875mm | 2.5mm | 3.0mm | |
| 单 |
物理密度 Pixel Density |
284444 / M2 | 160000 / M2 | 111111 / M2 |
| 元 |
发光点颜色 Pixel configuration |
1R1G1B | 1R1G1B | 1R1G1B |
| 板 |
灯体 LED specification |
SMD1515（HS） | SMD2020（HS） | SMD2020（HS） |
| Panel |
单元板分辨率 Pixel resolution |
（W）128*128（H） | （W）96*96（H） | （W）80*80（H） |
|
单元板平均功率 Average power |
35W | 24W | 24W | |
|
单元板电流 Panel current |
7A 5V | 4.8A 5V | 4.8A 5V | |
|
单元板重量 Panel weight |
380g | 380g | 380g | |
|
箱体 Cabinet& Bracket |
湿度 Humidity |
10%-95%RH | 10%-95%RH | 10%-95%RH |
|
单元板数量 Quantity of panel |
17.36 | 17.36 | 17.36 | |
|
单元板接口 Hub connecting |
HUB75 16pin | HUB75 16pin | HUB75 16pin | |
|
最佳视角 Best viewing angle |
Horizontal >140 Vertical>120 | Horizontal >140 Vertical>120 | Horizontal >140 Vertical>120 | |
|
最佳视距 Best viewing distance |
2-10M | 2-10M | 2-10M | |
|
工作温度 Working temperature |
-20~60 degree | -20~60 degree | -20~60 degree | |
|
单元板供电 Panel power supply |
5V40A | 5V40A | 5V40A | |
|
屏体供电 Screen power supply |
220VAC/50HZ+_10% | 220VAC/50HZ+_10% | 220VAC/50HZ+_10% | |
|
最大功率 Max power |
<650W/M² | <650W/M² | <650W/M² | |
|
平均功率 Average power |
200W | 200W | 200W | |
|
电源使用数量 Power quantity |
200W/4PCS | 200W/6PCS | 200W/6PCS | |
|
驱动器件 Driving device |
ICN2037 Constant current drive |
ICN2037 Constant current drive |
ICN2037 Constant current drive |
|
| 技 |
扫描方式 Drive type |
1/32 Scanning | 1/24 Scanning | 1/20 Scanning |
| 术 |
刷新频率 Refresh frequency |
≥1920HZ/S | ≥1920HZ/S | ≥1920HZ/S |
| 参 |
显示颜色 Display color |
4096*4096*4096 | 4096*4096*4096 | 4096*4096*4096 |
| 数 |
亮度 Brightness |
650 cd/M2 | 650 cd/M2 | 650 cd/M2 |
|
使用寿命 Life span |
100000Hours | 100000Hours | 100000Hours | |
|
防水等级 Waterproof Grade |
IP33 | IP33 | IP33 | |
| 分项Item | 技术参数 Technical parameter | ||
|
型号
Type
|
PH7.62 | F5.0 | |
|
单元板尺寸
Dimension
|
488mm*244mm | 488mm*244mm | |
|
点间距离
Pixel pitch
|
7.62mm | 7.62mm | |
| 单 |
物理密度
Pixel Density
|
17222 / M2 | 17222 / M2 |
| 元 |
发光点颜色
Pixel configuration
|
1R1G1B | 1Red |
| 板 |
灯体
LED specification
|
SMD3528（HS） | F5.0（HS） |
| Panel |
单元板分辨率
Pixel resolution
|
（W）64*32（H） | （W）64*32（H） |
|
单元板平均功率
Average power
|
35W | 28W | |
|
单元板电流
Panel current
|
7A 5V | 5.6A 5V | |
|
单元板重量
Panel weight
|
1kg | 1kg | |
|
箱体 Cabinet&
Bracket
|
湿度
Humidity
|
10%-95%RH | 10%-95%RH |
|
单元板数量
Quantity of panel
|
8.39 | 8.39 | |
|
单元板接口
Hub connecting
|
HUB75 16pin | HUB12 16pin | |
|
最佳视角
Best viewing angle
|
Horizontal >140 Vertical>120 | Horizontal >140 Vertical>120 | |
|
最佳视距
Best viewing distance
|
2-10M | 2-10M | |
|
工作温度
Working temperature
|
-20-~60 degree | -20-~60 degree | |
|
单元板供电
Panel power supply
|
5V40A | 5V40A | |
|
屏体供电
Screen power supply
|
220VAC/50HZ+_10% | 220VAC/50HZ+_10% | |
|
最大功率
Max power
|
<800W/M² | <800W/M² | |
|
平均功率
Average power
|
240W | 240W | |
|
电源使用数量
Power quantity
|
200W/4PCS | 200W/4PCS | |
|
驱动器件
Driving device
|
ICN2037
Constant current drive
|
JXI5020
Constant current drive
|
|
| 技 |
扫描方式
Drive type
|
1/8 Scanning | 1/8 Scanning |
| 术 |
刷新频率
Refresh frequency
|
≥1920HZ/S | ≥1920HZ/S |
| 参 |
显示颜色
Display color
|
4096*4096*4096 | 4096*4096*4096 |
| 数 |
亮度
Brightness
|
1000 cd/M2 | 1000 cd/M2 |
|
使用寿命
Life span
|
100000Hours | 100000Hours | |
|
防水等级
Waterproof Grade
|
IP33 | IP33 | |
| 分项Item | 技术参数 Technical parameter | ||
|
型号
Type
|
PH2.0 | PH3.0 | |
|
单元板尺寸
Dimension
|
192mm*96mm | 192mm*96mm | |
|
点间距离
Pixel pitch
|
2.0mm | 3.0mm | |
| 单 |
物理密度
Pixel Density
|
250000 / M2 | 111111/ M2 |
| 元 |
发光点颜色
Pixel configuration
|
1R1G1B | 1R1G1B |
| 板 |
灯体
LED specification
|
SMD1515（HG） | SMD2020（HG） |
| Panel |
单元板分辨率
Pixel resolution
|
（W）96*48（H） | （W）64*32（H） |
|
单元板平均功率
Average power
|
12W | 11W | |
|
单元板电流
Panel current
|
1.4A 5V | 1.4A 5V | |
|
单元板重量
Panel weight
|
155g | 155g | |
|
箱体 Cabinet&
Bracket
|
湿度
Humidity
|
10%-95%RH | 10%-95%RH |
|
单元板数量
Quantity of panel
|
54 | 54 | |
|
单元板接口
Hub connecting
|
HUB75 16pin | HUB75 16pin | |
|
最佳视角
Best viewing angle
|
Horizontal >140 Vertical>120 | Horizontal >140 Vertical>120 | |
|
最佳视距
Best viewing distance
|
2-10M | 3-20M | |
|
工作温度
Working temperature
|
-20-~60 degree | -20-~60 degree | |
|
单元板供电
Panel power supply
|
5V40A | 5V40A | |
|
屏体供电
Screen power supply
|
220VAC/50HZ+_10% | 220VAC/50HZ+_10% | |
|
最大功率
Max power
|
<650W/M² | <650W/M² | |
|
平均功率
Average power
|
200W | 200W | |
|
电源使用数量
Power quantity
|
200W/12PCS | 200W/12PCS | |
|
驱动器件
Driving device
|
ICN2037
Constant current drive
|
ICN2037
Constant current drive
|
|
| 技 |
扫描方式
Drive type
|
1/24 Scanning | 1/16 Scanning |
| 术 |
刷新频率
Refresh frequency
|
≥1920HZ/S | ≥1920HZ/S |
| 参 |
显示颜色
Display color
|
4096*4096*4096 | 4096*4096*4096 |
| 数 |
亮度
Brightness
|
800 cd/M2 | 1000 cd/M2 |
|
使用寿命
Life span
|
100000Hours | 100000Hours | |
|
防水等级
Waterproof Grade
|
IP33 | IP33 | |
中文版
英文版
