SMD P1.953 SMD P2.604 SMD P2.976 SMD P3.91 SMD P4.81
| 分项Item | 技术参数 Technical parameter | |||||
|
型号 Type |
PH1.953 | PH2.604 | PH2.976 | PH3.91 | PH4.81 | |
|
单元板尺寸 Dimension |
250mm*250mm | 250mm*250mm | 250mm*250mm | 250mm*250mm | 250mm*250mm | |
|
点间距离 Pixel pitch |
1.953mm | 2.604mm | 2.976mm | 3.91mm | 4.81mm | |
| 单 |
物理密度 Pixel Density |
262144 / M2 | 147456 / M2 | 112896 / M2 | 65536 / M2 | 43264 / M2 |
| 元 |
发光点颜色 Pixel configuration |
1R1G1B | 1R1G1B | 1R1G1B | 1R1G1B | 1R1G1B |
| 板 |
灯体 LED specification |
SMD1515（HS） | SMD2020（HS） | SMD2020（HS） | SMD2020（HS） | SMD2020（HS） |
| Panel |
单元板分辨率 Pixel resolution |
（W）128*128（H） | （W）96*96（H） | （W）84*84（H） | （W）64*64（H） | （W）52*52（H） |
|
单元板平均功率 Average power |
35W | 30W | 21W | 26W | 28W | |
|
单元板电流 Panel current |
7A 5V | 6A 5V | 4.2A 5V | 5.2A 5V | 5.6A 5V | |
|
单元板重量 Panel weight |
500g | 500g | 500g | 500g | 500g | |
|
箱体 Cabinet& Bracket |
湿度 Humidity |
10%-95%RH | 10%-95%RH | 10%-95%RH | 10%-95%RH | 10%-95%RH |
|
单元板数量 Quantity of panel |
16 | 16 | 16 | 16 | 16 | |
|
单元板接口 Hub connecting |
HUB75 16pin | HUB75 16pin | HUB75 16pin | HUB75 16pin | HUB75 16pin | |
|
最佳视角 Best viewing angle |
Horizontal >140 Vertical>120 | Horizontal >140 Vertical>120 | Horizontal >140 Vertical>120 | Horizontal >140 Vertical>120 | Horizontal >140 Vertical>120 | |
|
最佳视距 Best viewing distance |
2-10M | 3-10M | 3-10M | 4-20M | 5-30M | |
|
工作温度 Working temperature |
-20~60 degree | -20~60 degree | -20~60 degree | -20~60 degree | -20~60 degree | |
|
单元板供电 Panel power supply |
5V40A | 5V40A | 5V40A | 5V40A | 5V40A | |
|
屏体供电 Screen power supply |
220VAC/50HZ+_10% | 220VAC/50HZ+_10% | 220VAC/50HZ+_10% | 220VAC/50HZ+_10% | 220VAC/50HZ+_10% | |
|
最大功率 Max power |
<800W/M² | <800W/M² | <800W/M² | <800W/M² | <800W/M² | |
|
平均功率 Average power |
240W | 240W | 240W | 240W | 240W | |
|
电源使用数量 Power quantity |
200W/4PCS | 200W/4PCS | 200W/4PCS | 200W/4PCS | 200W/4PCS | |
|
驱动器件 Driving device |
ICN2037 Constant current drive |
ICN2037 Constant current drive |
ICN2037 Constant current drive |
ICN2037 Constant current drive |
ICN2037 Constant current drive |
|
| 技 |
扫描方式 Drive type |
1/32 Scanning | 1/32 Scanning | 1/26 Scanning | 1/16 Scanning | 1/13 Scanning |
| 术 |
刷新频率 Refresh frequency |
≥1920HZ/S | ≥1920HZ/S | ≥1920HZ/S | ≥1920HZ/S | ≥1920HZ/S |
| 参 |
显示颜色 Display color |
4096*4096*4096 | 4096*4096*4096 | 4096*4096*4096 | 4096*4096*4096 | 4096*4096*4096 |
| 数 |
亮度 Brightness |
800 cd/M2 | 800 cd/M2 | 800 cd/M2 | 800 cd/M2 | 800 cd/M2 |
|
使用寿命 Life span |
100000Hours | 100000Hours | 100000Hours | 100000Hours | 100000Hours | |
|
防水等级 Waterproof Grade |
IP33 | IP33 | IP33 | IP33 | IP33 | |
