| 技术参数 Technical parameter | |||
| 单元板尺寸 Dimension | 192mm*192mm | 192mm*192mm | 192mm*192mm |
|
点间距离 Pixel pitch |
1.5mm | 3.0mm | 6.0mm |
|
物理密度 Pixel Density |
444444 / M2 | 111111 / M2 | 27777 / M2 |
|
发光点颜色 Pixel configuration |
1R1G1B | 1R1G1B | 1R1G1B |
|
灯体 LED specification |
SMD1212(HG) | SMD2020(HG) | SMD3528(HG) |
| 单元板分辨率 Pixel resolution | (W)128*128(H) | (W)64*64(H) | (W)32*32(H) |
| 单元板平均功率 Average power | 15W | 15W | 24W |
| 单元板电流 Panel current | 3A 5V | 3A 5V | 4.8A 5V |
| 单元板重量 Panel weight | 300g | 300g | 300g |
|
湿度 Humidity |
10%-95%RH | 10%-95%RH | 10%-95%RH |
| 单元板数量 Quantity of panel | 27.12 | 27.12 | 27.12 |
|
单元板接口 Hub connecting |
HUB75 16pin | HUB75 16pin | HUB75 16pin |
|
最佳视角 Best viewing angle |
Horizontal >140 Vertical>120 | Horizontal >140 Vertical>120 | Horizontal >140 Vertical>120 |
| 最佳视距 Best viewing distance | 2-10M | 3-10M | 3-30M |
| 工作温度 Working temperature | -20~60 degree | -20~60 degree | -20~60 degree |
| 单元板供电 Panel power supply | 5V60A | 5V40A | 5V40A |
| 屏体供电 Screen power supply | 220VAC/50HZ+_10% | 220VAC/50HZ+_10% | 220VAC/50HZ+_10% |
|
最大功率 Max power |
<650W/M² | <600W/M² | <600W/M² |
|
平均功率 Average power |
200W | 180W | 180W |
| 电源使用数量 power quantity | 200W/9PCS | 200W/9PCS | 200W/8PCS |
|
驱动器件 Driving device |
FM6363 Constant current drive |
ICN2037 Constant current drive |
ICN2037 Constant current drive |
|
扫描方式 Drive type |
1/64 Scanning | 1/32 Scanning | 1/16 Scanning |
| 刷新频率 Refresh frequency | ≥3840HZ/S | ≥3840HZ/S | ≥3840HZ/S |
|
显示颜色 Display color |
4096*4096*4096 | 4096*4096*4096 | 4096*4096*4096 |
|
亮度 Brightness |
650 cd/M2 | 800 cd/M2 | 1000 cd/M2 |
|
使用寿命 Life span |
100000Hours | 100000Hours | 100000Hours |
|
防水等级 Waterproof Grade |
IP33 | IP33 | IP33 |
| SMD P7.62 |
| SMD P1.875 SMD P2.5 SMD P3.0 |
