SMD P4.75 单色 SMD P4.75 双色
P4.75 304mmx152mm 2020
P4.75 304mmx152mm 3825
| 分项Item | 技术参数 Technical parameter | |||
|
型号 Type |
PH4.75 | PH4.75 | PH4.75 | |
| 单元板尺寸 Dimension | 304mm*152mm | 304mm*152mm | 304mm*152mm | |
|
点间距离 Pixel pitch |
4.75mm | 4.75mm | 4.75mm | |
| 单 |
物理密度 Pixel Density |
44321 / M2 | 44321 / M2 | 44321 / M2 |
| 元 |
发光点颜色 Pixel configuration |
1R | 1R1G | 1R1G |
| 板 |
灯体 LED specification |
SMD2020 | SMD2020 | SMD3528 |
| Panel | 单元板分辨率 Pixel resolution | （W）64*32（H） | （W）64*32（H） | （W）32*16（H） |
| 单元板平均功率 Average power | 18W | 18W | 18W | |
| 单元板电流 Panel current | 3.6A 5V | 3.6A 5V | 3.6A 5V | |
| 单元板重量 Panel weight | 280g | 280g | 280g | |
|
箱体 Cabinet& Bracket |
湿度 Humidity |
10%-95%RH | 10%-95%RH | 10%-95%RH |
| 单元板数量 Quantity of panel | 21.64 | 21.64 | 21.64 | |
|
单元板接口 Hub connecting |
HUB12 16pin | HUB08 16pin | HUB08 16pin | |
|
最佳视角 Best viewing angle |
Horizontal >140 Vertical>120 | Horizontal >140 Vertical>120 | Horizontal >140 Vertical>120 | |
| 最佳视距 Best viewing distance | 4-10M | 4-10M | 8-30M | |
| 工作温度 Working temperature | -20~60 degree | -20~60 degree | -20~60 degree | |
| 单元板供电 Panel power supply | 5V40A | 5V40A | 5V40A | |
| 屏体供电 Screen power supply | 220VAC/50HZ+_10% | 220VAC/50HZ+_10% | 220VAC/50HZ+_10% | |
|
最大功率 Max power |
<389W/M² | <389W/M² | <389W/M² | |
|
平均功率 Average power |
116W | 116W | 116W | |
| 电源使用数量 power quantity | 200W/8PCS | 200W/8PCS | 200W/8PCS | |
|
驱动器件 Driving device |
INC2037 Constant current drive |
INC2037 Constant current drive |
ICN2037 Constant current drive |
|
| 技 |
扫描方式 Drive type |
1/16 Scanning | 1/16 Scanning | 1/16 Scanning |
| 术 | 刷新频率 Refresh frequency | ≥1920HZ/S | ≥1920HZ/S | ≥1920HZ/S |
| 参 |
显示颜色 Display color |
4096*4096*4096 | 4096*4096*4096 | 4096*4096*4096 |
| 数 |
亮度 Brightness |
800 cd/M2 | 800 cd/M2 | 1500 cd/M2 |
|
使用寿命 Life span |
100000Hours | 100000Hours | 100000Hours | |
|
防水等级 Waterproof Grade |
Front side & Back side IP33 | Front side & Back side IP33 | Front side & Back side IP33 | |
